1	`<?xml version="1.0" encoding="UTF-8"?>`
2	`<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "https://www.web3d.org/specifications/x3d-3.0.dtd">`
3	<X3D profile='Immersive' version='3.0' xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.0.xsd'>
4	<head>
5	<meta name='title' content=' DeadReckoningComparisons.x3d '/>
6	<meta name='description' content='Compare different dead-reckoning algorithms to see relative effects of velocity and acceleration on animation smoothness.'/>
7	<meta name='creator' content='Brian Hittner'/>
8	<meta name='translator' content=' Xeena VRML importer, X3D-Edit 3.1, https://www.web3d.org/x3d/content/README.X3D-Edit.html '/>
9	<meta name='created' content='11 June 2003'/>
10	<meta name='translated' content='12 June 2003'/>
11	<meta name='modified' content='20 October 2019'/>
12	<meta name='version' content='1.0'/>
13	<meta name='reference' content=' DeadReckoningComparisons/Project4.java '/>
14	<meta name='reference' content='vrml97.jar'/>
15	<meta name='reference' content='DeadReckoningComparisons/README.TXT'/>
16	<meta name=' warning ' content=' CLASSPATH needs to include location of DeadReckoningComparisons/Project4.jar '/>
17	<meta name='subject' content='dead reckoning'/>
18	<meta name='identifier' content=' https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/DeadReckoningComparisons.x3d '/>
19	<meta name='generator' content='X3D-Edit 3.3, https://www.web3d.org/x3d/tools/X3D-Edit'/>
20	<meta name='generator' content=' Vrml97ToX3dNist, http://ovrt.nist.gov/v2_x3d.html '/>
21	<meta name='license' content='../license.html'/>
22	</head>

<!--

Event Graph ROUTE Table shows event connections.

-->
<!--

DEF nodes index: Clock, Movement, myMessage, SpherePosition

Index for Viewpoint node: Viewpoint_1

-->

23	<Scene>
24	<WorldInfo title='DeadReckoningComparisons.x3d'/>
25	<Viewpoint description='Dead Reckoning Comparisons' position='0.0 0.0 15.0'/>
26	<Group>
27	<!-- ROUTE information for SpherePosition node: [from Movement.position_changed to translation ] --> <Transform DEF='SpherePosition'>
28	<Group>
29	<Shape>
30	<Appearance>
31	<Material diffuseColor='1.0 0.1 0.1'/>
32	</Appearance>
33	<Sphere/>
34	</Shape>
35	</Group>
36	<!-- ROUTE information for Clock node: [from fraction_changed to Movement.set_time ] --> <TimeSensor DEF='Clock' cycleInterval='5.0' loop='true'/>
37	<!-- Warning: VRML97-style scripting, not X3D Scene Authoring Interface (SAI) -->
38	<!-- ROUTE information for Movement node: [from Clock.fraction_changed to set_time ] [from position_changed to SpherePosition.translation ] [from text_changed to myMessage.string ] --> <Script DEF='Movement' url=' "DeadReckoningComparisons/Project4.class" "https://www.web3d.org/x3d/content/examples/Basic/StudentProjects/DeadReckoningComparisons/Project4.class" '>
39	<field name='set_time' type='SFFloat' accessType='inputOnly'/>
40	<field name='position_changed' type='SFVec3f' accessType='outputOnly'/>
41	<field name='text_changed' type='MFString' accessType='outputOnly'/>
42	</Script>
43	</Transform>
44	<Transform translation='-4.0 0.0 0.0'>
45	<Shape>
46	<Appearance>
47	<Material/>
48	</Appearance>
49	<!-- ROUTE information for myMessage node: [from Movement.text_changed to string ] --> <Text DEF='myMessage' string='"Test String"'/>
50	</Shape>
51	</Transform>
52	</Group>
53	< ROUTE fromNode='Clock' fromField='fraction_changed' toNode='Movement' toField='set_time'/>
54	< ROUTE fromNode='Movement' fromField='position_changed' toNode='SpherePosition' toField='translation'/>
55	< ROUTE fromNode='Movement' fromField='text_changed' toNode='myMessage' toField='string'/>
56	</Scene>
57	</X3D>

<!--

Event Graph ROUTE Table shows event connections.

-->
<!--

DEF nodes index: Clock, Movement, myMessage, SpherePosition

Index for Viewpoint node: Viewpoint_1

-->

X3D Tooltips element index: Appearance, field, Group, head, Material, meta, ROUTE, Scene, Script, Shape, Sphere, Text, TimeSensor, Transform, Viewpoint, WorldInfo, X3D, plus documentation for accessType definitions, type definitions, XML data types, and field types

Event Graph ROUTE Table entries with 3 ROUTE connections total, showing X3D event-model relationships for this scene.

Each row shows an event cascade that may occur during a single timestamp interval between frame renderings, as part of the X3D execution model.

Clock TimeSensor fraction_changed SFFloat	→ ROUTE event to (1)	Movement Script set_time SFFloat	then	Movement Script position_changed SFVec3f	→ ROUTE event to (2)	SpherePosition Transform translation SFVec3f
			then	Movement Script text_changed MFString	→ ROUTE event to (2)	myMessage Text string MFString

Additional guidance on X3D animation can be found in the 10-Step Animation Design Process and Event Tracing hint sheets. Have fun with X3D! 😀

-->
