X3D Model Documentation: LineBoatPrototype.x3d

---

<!--

Event Graph ROUTE Table shows event connections.

-->
<!-- DEF nodes index: Boat, BoatPosit, BoatPositClock, BoatTransform, DeadBoat, DeadOrient, FRONT, REAR, STBD, TEXTURE, Touch

Index for Viewpoint nodes: Viewpoint_1, Viewpoint_2, FRONT, REAR, STBD

Index for ProtoDeclare definition: LineBoat

17	<Scene>
18	<WorldInfo title='LineBoatPrototype.x3d'/>
19	<ProtoDeclare name='LineBoat'>
20	<ProtoInterface>
21	<field name='startExplosion' type='SFTime' accessType='inputOnly'/>
22	</ProtoInterface>
23	<ProtoBody>
24	<Group>
25	<Transform>
26	<Viewpoint DEF='STBD' description='Line Boat stbd View' jump='false' orientation='1 0 0 -0.2' position='5 10 35'/>
27	<Viewpoint DEF='REAR' description='Line Boat Rear View' jump='false' orientation='0 1 0 -1.57' position='-30 8 0'/>
28	<Viewpoint description='Line Boat Port View' jump='false' orientation='0 1 0 3.14' position='5 8 -30'/>
29	<Viewpoint DEF='FRONT' description='Line Boat Front View' jump='false' orientation='0 1 0 1.57' position='32 8 0'/>
30	</Transform>
31	<!-- ROUTE information for BoatPosit node:  [from BoatPositClock.fraction_changed to set_fraction ] [from value_changed to BoatTransform.set_translation ] -->                          <PositionInterpolator DEF='BoatPosit' key='0.325 0.9 1' keyValue='0 0 0 0 -15 0 0 -.5 0'/>
32	<!-- ROUTE information for BoatPositClock node:  [from fraction_changed to BoatPosit.set_fraction ] [from startTime to DeadBoat.set_startTime ] -->                          <TimeSensor DEF='BoatPositClock' cycleInterval='3.6'>
33	<IS>
34	<connect nodeField='startTime' protoField='startExplosion'/>
35	</IS>
36	</TimeSensor>
37	<!-- ROUTE information for DeadBoat node:  [from BoatPositClock.startTime to set_startTime ] [from fraction_changed to DeadOrient.set_fraction ] -->                          <TimeSensor DEF='DeadBoat' cycleInterval='5'/>
38	<!-- ROUTE information for DeadOrient node:  [from DeadBoat.fraction_changed to set_fraction ] [from value_changed to BoatTransform.set_rotation ] -->                          <OrientationInterpolator DEF='DeadOrient' key='0.4 0.9 1' keyValue='1 0 0 0.00 1 0 0 3.14 1 0 0 3.14'/>
39	<!-- ROUTE information for BoatTransform node:  [from BoatPosit.value_changed to set_translation ] [from DeadOrient.value_changed to set_rotation ] -->                          <Transform DEF='BoatTransform'>
40	<Transform scale='1.2 1.2 1.2'>
41	<Shape>
42	<Extrusion creaseAngle='1.57' crossSection='0.00 1.00 0.38 0.92 0.71 0.71 0.92 0.38 1.00 0.00 0.92 -0.38 0.71 -0.71 0.38 -0.92 0.00 -1.00' orientation='0 1 0 0 0 1 0 0 0 0 1 -0.5' scale='1 1 1 1 1 .1' solid='false' spine='0 0 0 7.8842 0 0 10.7 0.25 0'/>
43	<Appearance>
44	<Material diffuseColor='.9 .9 .9' shininess='.1'/>
45	<!-- ImageTexture TEXTURE is a DEF node that has 1 USE node: USE_1 -->                                              <ImageTexture DEF='TEXTURE'   url=' "../../Scenarios/UssColeTerroristAttack/BoatTexture.jpg " "BoatTexture.jpg " "https://www.web3d.org/x3d/content/examples/Savage/Scenarios/UssColeTerroristAttack/BoatTexture.jpg " '/>
46	</Appearance>
47	</Shape>
48	<Shape>
49	<Extrusion creaseAngle='1.57' crossSection='0.10 0.96 0.10 -0.96' scale='1 1 1 1 1 .1' solid='false' spine='.1 0 0 7.8842 0 0 10.6 0.25 0'/>
50	<Appearance>
51	<Material diffuseColor='1 1 1'/>
52	<ImageTexture USE='TEXTURE'/>
53	</Appearance>
54	</Shape>
55	</Transform>
56	<Transform translation='0 -.2 0'>
57	<Shape>
58	<IndexedFaceSet solid='false' coordIndex='0 2 6 4 0 -1 1 3 7 5 1 -1 0 1 5 4 0 -1 2 3 7 6 2 -1 4 6 7 5 4 -1'>
59	<Coordinate point='2 0 .5 3 0 .5 2 0 -.5 3 0 -.5 2 1 .5 3 1.5 .5 2 1 -.5 3 1.5 -.5'/>
60	</IndexedFaceSet>
61	<Appearance>
62	<Material diffuseColor='.9 .9 .9'/>
63	</Appearance>
64	</Shape>
65	</Transform>
66	</Transform>
67	< ROUTE  fromNode='BoatPositClock' fromField='fraction_changed' toNode='BoatPosit' toField='set_fraction'/>
68	< ROUTE  fromNode='BoatPosit' fromField='value_changed' toNode='BoatTransform' toField='set_translation'/>
69	< ROUTE  fromNode='BoatPositClock' fromField='startTime' toNode='DeadBoat' toField='set_startTime'/>
70	< ROUTE  fromNode='DeadBoat' fromField='fraction_changed' toNode='DeadOrient' toField='set_fraction'/>
71	< ROUTE  fromNode='DeadOrient' fromField='value_changed' toNode='BoatTransform' toField='set_rotation'/>
72	</Group>
73	</ProtoBody>
74	</ProtoDeclare>
75	<NavigationInfo speed='10' type='"EXAMINE" "FLY" "ANY"' visibilityLimit='7000'/>
76	<Background groundAngle='1.309 1.570796' groundColor='0.1 0.1 0 0.4 0.25 0.2 0.6 0.6 0.6' skyAngle='1.309 1.571' skyColor='0 0.2 0.7 0 0.5 1 1 1 1'/>
77	<!-- ROUTE information for Boat node:  [from Touch.touchTime to startExplosion ] -->           <ProtoInstance name='LineBoat' DEF='Boat'/>
78	<Viewpoint description='Line Boat View' jump='false' orientation='1 0 0 -0.2' position='0 10 35'/>
79	<!-- ROUTE information for Touch node:  [from touchTime to Boat.startExplosion ] -->           <TouchSensor DEF='Touch' description='Flips boat over on touch'/>
80	< ROUTE  fromNode='Touch' fromField='touchTime' toNode='Boat' toField='startExplosion'/>
81	</Scene>
82	</X3D>

---

<!--
