X3D Model Documentation: Frigate.x3d

  1  <?xml version="1.0" encoding="UTF-8"?>
  2
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.0//EN" "https://www.web3d.org/specifications/x3d-3.0.dtd">
  3  <X3D profile='Immersive' version='3.0'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.0.xsd'>
  4       <head>
  5            <meta name='title' content=' Frigate.x3d '/>
  6            <meta name='creator' content='Copyright [2001] By George Stavritis'/>
  7            <meta name='created' content='28 February 2001'/>
  8            <meta name='modified' content='20 October 2019'/>
  9            <meta name='description' content='The complete Hellenic Frigate Adrias.'/>
 10            <meta name='identifier' content=' https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/Frigate.x3d '/>
 11            <meta name='generator' content='X3D-Edit 3.2, https://www.web3d.org/x3d/tools/X3D-Edit'/>
 12            <meta name='license' content='../../license.html'/>
 13       </head>
<!--
<!-- to top DEF node index: Index for Viewpoint node: Viewpoint_1
-->
 14       <Scene>
 15            <WorldInfo title='Frigate.x3d'/>
 16            <Viewpoint description='Extruded ship hull and deck' orientation='0 1 0 0.4' position='0 10 100'/>
 17            <!-- The helicopter hagar -->
 18            <Transform translation='-30 -11 0'>
 19                 <Shape>
 20                      <Extrusion crossSection='-130 10 -100 -30 -80 -50 -50 -60 50 -60 80 -50 100 -30 130 10' spine='0 -12 0 0 120 0'/>
 21                      <Appearance>
 22                           <ImageTexture   url=' "kastelorizo.jpg " "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/kastelorizo.jpg " '/>
 23                      </Appearance>
 24                 </Shape>
 25            </Transform>
 26            <Transform translation='0 -9 0'>
 27                 <Shape>
 28                      <Box size='200 1 100'/>
 29                      <Appearance>
 30                           <ImageTexture   url=' "sea2.jpg " "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/sea2.jpg " '/>
 31                      </Appearance>
 32                 </Shape>
 33            </Transform>
 34            <Transform rotation='1 0 0 1.57' scale='10 10 10'>
 35                 <Inline   url=' "noGrid20x20.x3d" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/noGrid20x20.x3d" "noGrid20x20.wrl" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/noGrid20x20.wrl" '/>
 36            </Transform>
 37            <Transform scale='10 10 10' translation='0 -10 0'>
 38                 <Inline   url=' "noGrid20x20.x3d" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/noGrid20x20.x3d" "noGrid20x20.wrl" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/noGrid20x20.wrl" '/>
 39            </Transform>
 40            <Transform rotation='0 1 0 -1.57' translation='-65 0 0'>
 41                 <Inline   url=' "helideck.x3d" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/helideck.x3d" "helideck.wrl" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/helideck.wrl" '/>
 42            </Transform>
 43            <!-- The main hull of the ship -->
 44            <Transform>
 45                 <Inline   url=' "hull.x3d" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/hull.x3d" "hull.wrl" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/hull.wrl" '/>
 46            </Transform>
 47            <Transform scale='2 2 2' translation='10 0 0'>
 48                 <Inline   url=' "OtoMelara.x3d" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/OtoMelara.x3d" "OtoMelara.wrl" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/OtoMelara.wrl" '/>
 49                 <Sound maxBack='150' maxFront='140'>
 50                      <AudioClip loop='true'   url=' "biggun.wav" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/biggun.wav" '/>
 51                 </Sound>
 52            </Transform>
 53            <Transform rotation='0 1 0 3.14' scale='2 2 2' translation='-80 6 0'>
 54                 <Inline   url=' "Otomelara.x3d" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/Otomelara.x3d" "Otomelara.wrl" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/Otomelara.wrl" '/>
 55            </Transform>
 56            <Transform scale='5 5 5' translation='-70 10 0'>
 57                 <Inline   url=' "Radar2.x3d" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/Radar2.x3d" "Radar2.wrl" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/Radar2.wrl" '/>
 58            </Transform>
 59            <Transform>
 60                 <Sound location='0 20 70' maxBack='150' maxFront='140'>
 61                      <AudioClip loop='true'   url=' "aircombt.wav" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/aircombt.wav" '/>
 62                 </Sound>
 63            </Transform>
 64            <Transform rotation='0 1 0 1.57' translation='-25 0 0'>
 65                 <Inline   url=' "OfficerMess.x3d" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/OfficerMess.x3d" "OfficerMess.wrl" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/OfficerMess.wrl" '/>
 66            </Transform>
 67            <Transform rotation='0 1 0 1.57' translation='-20 3 0'>
 68                 <Inline   url=' "COroom.x3d" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/COroom.x3d" "COroom.wrl" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/COroom.wrl" '/>
 69            </Transform>
 70            <Transform rotation='0 1 0 1.57' translation='-14 6 0'>
 71                 <Inline   url=' "Bridge.x3d" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/Bridge.x3d" "Bridge.wrl" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/Bridge.wrl" '/>
 72            </Transform>
 73            <Transform scale='0.6 1.2 0.6' translation='-18 3 0'>
 74                 <Inline   url=' "Pyramid.x3d" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/Pyramid.x3d" "Pyramid.wrl" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/Pyramid.wrl" '/>
 75            </Transform>
 76            <Transform scale='1 4 1' translation='-19 12 0'>
 77                 <Inline   url=' "MainMast.x3d" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/MainMast.x3d" "MainMast.wrl" "https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/FrigateGreece/MainMast.wrl" '/>
 78            </Transform>
 79       </Scene>
 80  </X3D>
<!--
<!-- to top DEF node index: Index for Viewpoint node: Viewpoint_1
-->
