| 3 | <X3D profile='Immersive' version='3.0' xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.0.xsd'> |
| 4 | <head> |
| 5 | <meta name='title' content=' WellDeck.x3d '/> |
| 6 | <meta name='creator' content='LT Patricia Sweat USN'/> |
| 7 | <meta name='description' content='Large Deck Amphibious Ship: USS BOXER (LHD 4)'/> |
| 8 | <meta name='identifier' content=' https://www.web3d.org/x3d/content/examples/Savage/ShipsMilitary/LargeDeckAmphibBoxerUnitedStates/WellDeck.x3d '/> |
| 9 | <meta name='created' content='20 August 2004'/> |
| 10 | <meta name='modified' content='28 January 2024'/> |
| 11 | <meta name='generator' content='X3D-Edit 3.2, https://www.web3d.org/x3d/tools/X3D-Edit'/> |
| 12 | <meta name='license' content='../../license.html'/> |
| 13 | </head> |
DEF nodes index:
ConsoleOutputViewPositionOrientation,
GREY,
Patty_Sweat,
WellDeck_Open,
WellDoorSensor,
WellDoorSensor1,
WellDoorTransform,
WellDoorTransform1
| 14 | <Scene> |
| 15 | <WorldInfo title='WellDeck.x3d'/> |
| 16 | <Viewpoint description='Sterngate' orientation='0.58 -0.64 -0.504 2.3848' position='-58.6 14.8 -28.4'/> |
| 17 | <Transform rotation='0 0 1 1'/> |
| 18 | <Group DEF='Patty_Sweat'> |
| 19 | <Transform DEF='WellDeck_Open'> |
| 20 |
<!-- ROUTE information for WellDoorSensor1 node:
[from rotation_changed to WellDoorTransform1.set_rotation
]
-->
<CylinderSensor DEF='WellDoorSensor1' description='click and drag to rotate' maxAngle='1.57'/> |
| 21 | <Transform> |
| 22 |
<!-- ROUTE information for WellDoorTransform1 node:
[from WellDoorSensor1.rotation_changed to set_rotation
]
-->
<Transform DEF='WellDoorTransform1'> |
| 23 | <Shape> |
| 24 | <Extrusion crossSection='-16.5 -10 16.5 -10 11.5 -21 -11.5 -21 -16.5 -10' scale='1 1 1 1' spine='-0.4 5 0 0.1 5 0'/> |
| 25 | <Appearance> |
| 26 | <Material DEF='GREY' ambientIntensity='1' diffuseColor='.8 .8 .8'/> |
| 27 | </Appearance> |
| 28 | </Shape> |
| 29 | </Transform> |
| 30 | </Transform> |
| 31 | </Transform> |
| 32 | < ROUTE fromNode='WellDoorSensor1' fromField='rotation_changed' toNode='WellDoorTransform1' toField='set_rotation'/> |
| 33 | <Transform> |
| 34 |
<!-- ROUTE information for WellDoorSensor node:
[from rotation_changed to WellDoorTransform.set_rotation
]
-->
<CylinderSensor DEF='WellDoorSensor' description='click and drag to rotate' maxAngle='1.57'/> |
| 35 |
<!-- ROUTE information for WellDoorTransform node:
[from WellDoorSensor.rotation_changed to set_rotation
]
-->
<Transform DEF='WellDoorTransform'> |
| 36 | <Transform> |
| 37 | <Shape> |
| 38 | <Extrusion creaseAngle='.7' crossSection='-21.3 0 0 0 21.3 0 16.5 -10 -16.5 -10 -21.3 0' scale='1 1 1 1' solid='false' spine='-0.4 5 0 0.1 5 0'/> |
| 39 | <Appearance> |
| 40 | <Material diffuseColor='1 0 0'/> |
| 41 | </Appearance> |
| 42 | </Shape> |
| 43 | </Transform> |
| 44 | </Transform> |
| 45 | </Transform> |
| 46 | < ROUTE fromNode='WellDoorSensor' fromField='rotation_changed' toNode='WellDoorTransform' toField='set_rotation'/> |
| 47 | </Group> |
