X3D Model Documentation: BlueRockFish.x3d

  1  <?xml version="1.0" encoding="UTF-8"?>
  2  <!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.3//EN" "https://www.web3d.org/specifications/x3d-3.3.dtd">
  3  <X3D profile='Immersive' version='3.3'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.3.xsd'>
  4       <head>
  5            <meta name='title' content=' BlueRockFish.x3d '/>
  6            <meta name='description' content='Create a new fish type through configuration of the CircleFishLod prototype.'/>
  7            <meta name='creator' content='Ildeniz Duman'/>
  8            <meta name='translator' content='Jeff Weekley'/>
  9            <meta name='created' content='1 May 1998'/>
 10            <meta name='translated' content='25 February 2001'/>
 11            <meta name='modified' content='20 October 2019'/>
 12            <meta name='identifier' content=' https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/KelpForestExhibit/BlueRockFish.x3d '/>
 13            <meta name='generator' content='X3D-Edit 3.3, https://www.web3d.org/x3d/tools/X3D-Edit'/>
 14            <meta name='license' content='../license.html'/>
 15       </head>
<!--
<!--
Event Graph ROUTE Table shows event connections.
-->
<!-- to top DEF nodes index: BlueRockfish, BlueRockfish1, BlueRockfish2, BlueRockfish3, BlueRockfish4

Index for Viewpoint node: Viewpoint_1

Index for ExternProtoDeclare definition: CircleFishLod
-->
 16       <Scene>
 17            <WorldInfo title='BlueRockFish.x3d'/>
 18            <ExternProtoDeclare name='CircleFishLod' appinfo='CircleFish prototype with LOD added'   url=' "CircleFishLodPrototype.x3d#CircleFishLod" "https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/KelpForestExhibit/CircleFishLodPrototype.x3d#CircleFishLod" "CircleFishLodPrototype.wrl#CircleFishLod" "https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/KelpForestExhibit/CircleFishLodPrototype.wrl#CircleFishLod" '>
 19                 <field name='skinTextureUrl' type='MFString' accessType='inputOutput'/>
 20                 <field name='fishScale' type='SFVec3f' accessType='inputOutput'/>
 21                 <field name='fishColor' type='SFColor' accessType='inputOutput'/>
 22                 <field name='finColor' type='SFColor' accessType='inputOutput'/>
 23                 <field name='positionKey' type='MFFloat' accessType='inputOutput'/>
 24                 <field name='positionKeyValue' type='MFVec3f' accessType='inputOutput'/>
 25                 <field name='orientationKey' type='MFFloat' accessType='inputOutput'/>
 26                 <field name='orientationKeyValue' type='MFRotation' accessType='inputOutput'/>
 27                 <field name='orbitTime' type='SFTime' accessType='inputOutput'/>
 28            </ExternProtoDeclare>
 29            <Viewpoint description='Blue Rockfish' position='-1 1 8'/>
 30            <Transform>
 31                 <ProtoInstance name='CircleFishLod' DEF='BlueRockfish'>
 32                      <fieldValue name='skinTextureUrl' value=' "blueRockfishPatch.jpg" "https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/KelpForestExhibit/blueRockfishPatch.jpg"'/>
 33                      <fieldValue name='fishScale' value='0.5 0.53 0.2'/>
 34                      <fieldValue name='fishColor' value='0.2 0.6 0.8'/>
 35                      <fieldValue name='positionKey' value='0 0.3 0.6 1'/>
 36                      <fieldValue name='positionKeyValue' value='0 0 1 1 0 0 0 0 -1 0 0 1'/>
 37                      <fieldValue name='orbitTime' value='60'/>
 38                 </ProtoInstance>
 39            </Transform>
 40            <Transform rotation='0 1 0 1.05' translation='0 0.5 0'>
 41                 <!-- rotation 60 degrees -->
 42                 <ProtoInstance name='CircleFishLod' DEF='BlueRockfish1'>
 43                      <fieldValue name='skinTextureUrl' value=' "blueRockfishPatch.jpg" "https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/KelpForestExhibit/blueRockfishPatch.jpg"'/>
 44                      <fieldValue name='fishScale' value='0.5 0.53 0.2'/>
 45                      <fieldValue name='fishColor' value='0.2 0.6 0.8'/>
 46                      <fieldValue name='positionKey' value='0 0.3 0.6 1'/>
 47                      <fieldValue name='positionKeyValue' value='0 0 1 1 0 0 0 0 -1 0 0 1'/>
 48                      <fieldValue name='orbitTime' value='60'/>
 49                 </ProtoInstance>
 50            </Transform>
 51            <Transform translation='0 1.5 1'>
 52                 <ProtoInstance name='CircleFishLod' DEF='BlueRockfish2'>
 53                      <fieldValue name='skinTextureUrl' value=' "blueRockfishPatch.jpg" "https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/KelpForestExhibit/blueRockfishPatch.jpg"'/>
 54                      <fieldValue name='fishScale' value='0.5 0.53 0.2'/>
 55                      <fieldValue name='fishColor' value='0.2 0.6 0.8'/>
 56                      <fieldValue name='positionKey' value='0 0.3 0.6 1'/>
 57                      <fieldValue name='positionKeyValue' value='0 0 1 1 0 0 0 0 -1 0 0 1'/>
 58                      <fieldValue name='orbitTime' value='40'/>
 59                 </ProtoInstance>
 60            </Transform>
 61            <Transform rotation='0 1 0 0.78' translation='-0.5 1 0'>
 62                 <!-- rotation 45 degrees -->
 63                 <ProtoInstance name='CircleFishLod' DEF='BlueRockfish3'>
 64                      <fieldValue name='skinTextureUrl' value=' "blueRockfishPatch.jpg" "https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/KelpForestExhibit/blueRockfishPatch.jpg"'/>
 65                      <fieldValue name='fishScale' value='0.5 0.53 0.2'/>
 66                      <fieldValue name='fishColor' value='0.2 0.6 0.8'/>
 67                      <fieldValue name='positionKey' value='0 0.4 0.7 0.95 1'/>
 68                      <fieldValue name='positionKeyValue' value='0 0 0 1 0 0 0 0 0 1 0 0 0.3 0 0'/>
 69                      <fieldValue name='orientationKey' value='0 0.5 1'/>
 70                      <fieldValue name='orientationKeyValue' value='0 1 0 0 0 1 0 1.57 0 1 0 0'/>
 71                      <fieldValue name='orbitTime' value='80'/>
 72                 </ProtoInstance>
 73            </Transform>
 74            <Transform translation='0 1.8 2'>
 75                 <ProtoInstance name='CircleFishLod' DEF='BlueRockfish4'>
 76                      <fieldValue name='skinTextureUrl' value=' "blueRockfishPatch.jpg" "https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/KelpForestExhibit/blueRockfishPatch.jpg"'/>
 77                      <fieldValue name='fishScale' value='0.5 0.53 0.2'/>
 78                      <fieldValue name='fishColor' value='0.2 0.6 0.8'/>
 79                      <fieldValue name='positionKey' value='0 0.3 0.6 1'/>
 80                      <fieldValue name='positionKeyValue' value='0 0 1 1 0 0 0 0 -3 0 0 1'/>
 81                      <fieldValue name='orbitTime' value='40'/>
 82                 </ProtoInstance>
 83            </Transform>
 84       </Scene>
 85  </X3D>
<!--
<!--
Event Graph ROUTE Table shows event connections.
-->
<!-- to top DEF nodes index: BlueRockfish, BlueRockfish1, BlueRockfish2, BlueRockfish3, BlueRockfish4

Index for Viewpoint node: Viewpoint_1

Index for ExternProtoDeclare definition: CircleFishLod
-->
X3D Tooltips element index: ExternProtoDeclare, field, fieldValue, head, meta, ProtoInstance, Scene, Transform, Viewpoint, WorldInfo, X3D, plus documentation for accessType definitions, type definitions, XML data types, and field types

Event Graph ROUTE Table with 0 ROUTE connections total, showing X3D event-model relationships for this scene.

Each row shows an event cascade that may occur during a single timestamp interval between frame renderings, as part of the X3D execution model.

BlueRockfish
ProtoInstance
CircleFishLod 		No direct ROUTE connection found for events to/from this node.
This ProtoInstance contains SFNode/MFNode fieldValue declarations with
direct access to other nodes, and thus has potential to produce run-time animation.

BlueRockfish1
ProtoInstance
CircleFishLod 		No direct ROUTE connection found for events to/from this node.
This ProtoInstance contains SFNode/MFNode fieldValue declarations with
direct access to other nodes, and thus has potential to produce run-time animation.

BlueRockfish2
ProtoInstance
CircleFishLod 		No direct ROUTE connection found for events to/from this node.
This ProtoInstance contains SFNode/MFNode fieldValue declarations with
direct access to other nodes, and thus has potential to produce run-time animation.

BlueRockfish3
ProtoInstance
CircleFishLod 		No direct ROUTE connection found for events to/from this node.
This ProtoInstance contains SFNode/MFNode fieldValue declarations with
direct access to other nodes, and thus has potential to produce run-time animation.

BlueRockfish4
ProtoInstance
CircleFishLod 		No direct ROUTE connection found for events to/from this node.
This ProtoInstance contains SFNode/MFNode fieldValue declarations with
direct access to other nodes, and thus has potential to produce run-time animation.

Additional guidance on X3D animation can be found in the 10-Step Animation Design Process and Event Tracing hint sheets. Have fun with X3D! 😀
-->
<!-- Online at
https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/KelpForestExhibit/BlueRockFishIndex.html -->
<!-- Version control at
https://sourceforge.net/p/x3d/code/HEAD/tree/www.web3d.org/x3d/content/examples/X3dForWebAuthors/KelpForestExhibit/BlueRockFish.x3d -->

<!-- Color-coding legend: X3D terminology <X3dNode  DEF='idName' field='value'/> matches XML terminology <XmlElement  DEF='idName' attribute='value'/>
(Light-blue background: event-based behavior node or statement) (Grey background inside box: inserted documentation) (Magenta background: X3D Extensibility)
    <ProtoInstance name='ProtoName'> <field name='fieldName'/> </ProtoInstance> -->

to top <!-- For additional help information about X3D scenes, please see X3D Tooltips, X3D Resources, and X3D Scene Authoring Hints. -->
