<?xml version="1.0" encoding="UTF-8"?>
|
| 2 |
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.3//EN" "https://www.web3d.org/specifications/x3d-3.3.dtd">
|
| 3 | <X3D profile='Interactive' version='3.3' xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.3.xsd'> |
| 4 | <head> |
| 5 | <meta name='title' content=' StripedSurfPerchPlaque.x3d '/> |
| 6 | <meta name='creator' content='Michael Collins'/> |
| 7 | <meta name='created' content='18 February 2001'/> |
| 8 | <meta name='modified' content='20 October 2019'/> |
| 9 | <meta name=' warning ' content=' under development '/> |
| 10 | <meta name='description' content='One fish plaque with lithograph on one side and actual picture on the back. Click on plaque to go to picture or click on buttons to change picture.'/> |
| 11 | <meta name='identifier' content=' https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/KelpForestExhibit/StripedSurfPerchPlaque.x3d '/> |
| 12 | <meta name='generator' content='X3D-Edit 3.3, https://www.web3d.org/x3d/tools/X3D-Edit'/> |
| 13 |
<meta name='Image' content='StripedSurfPerchPatch.jpg' />
|
| 14 |
<meta name='Image' content='RainbowSurfPerch002.jpg' />
|
| 15 | <meta name='license' content='../license.html'/> |
| 16 | </head> |
DEF nodes index:
BASE_TRANSFORM,
BaseTouchSensor,
BLUEROCKFISH_TRANSFORM,
BLUEROCKFISHCLOCK,
BlueRockfishPathInterpolator,
BlueRockfishTouchSensor,
BUTTON_TRANSFORM,
BUTTON_TRANSFORM2,
FrontTouchSensor,
FRONTTOUCHSENSORCLOCK,
PictureTouchSensor,
PlaqueToPictureInterpolator,
stripedsurfperch
| 17 | <Scene> |
| 18 | <WorldInfo title='StripedSurfPerchPlaque.x3d'/> |
| 19 | <Viewpoint DEF='stripedsurfperch' description='Striped Surf Perch' position='0 0 4'/> |
| 20 | <!-- Fish Plaques --> |
| 21 | <Group> |
| 22 |
<!-- ROUTE information for BlueRockfishTouchSensor node:
[from touchTime to BLUEROCKFISHCLOCK.set_startTime
]
-->
<TouchSensor DEF='BlueRockfishTouchSensor' description='touch to rotate'/> |
| 23 |
<!-- ROUTE information for BLUEROCKFISHCLOCK node:
[from BlueRockfishTouchSensor.touchTime to set_startTime
]
[from PictureTouchSensor.touchTime to set_startTime
]
[from fraction_changed to BlueRockfishPathInterpolator.set_fraction
]
-->
<TimeSensor DEF='BLUEROCKFISHCLOCK' cycleInterval='2'/> |
| 24 |
<!-- ROUTE information for BlueRockfishPathInterpolator node:
[from BLUEROCKFISHCLOCK.fraction_changed to set_fraction
]
[from value_changed to BLUEROCKFISH_TRANSFORM.set_rotation
]
-->
<OrientationInterpolator DEF='BlueRockfishPathInterpolator' key='0.0 0.50 1.0' keyValue='0.0 1.0 0.0 0.0 0.0 1.0 0.0 1.57 0.0 1.0 0.0 3.14'/> |
| 25 |
<!-- ROUTE information for BLUEROCKFISH_TRANSFORM node:
[from BlueRockfishPathInterpolator.value_changed to set_rotation
]
[from PlaqueToPictureInterpolator.value_changed to set_rotation
]
-->
<Transform DEF='BLUEROCKFISH_TRANSFORM'> |
| 26 | <Shape> |
| 27 | <Box size='4 2 .1'/> |
| 28 | <Appearance> |
| 29 |
<ImageTexture
url=' "StripedSurfPerchPatch.jpg
" "https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/KelpForestExhibit/StripedSurfPerchPatch.jpg
" '/>
|
| 30 | </Appearance> |
| 31 | </Shape> |
| 32 | <Transform translation='0 0 -.1'> |
| 33 | <Shape> |
| 34 | <Box size='4 2 .2'/> |
| 35 | <Appearance> |
| 36 |
<ImageTexture
url=' "RainbowSurfPerch002.jpg
" "https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/KelpForestExhibit/RainbowSurfPerch002.jpg
" '/>
|
| 37 | </Appearance> |
| 38 | </Shape> |
| 39 | </Transform> |
| 40 | </Transform> |
| 41 | <Group> |
| 42 | <Transform DEF='BUTTON_TRANSFORM' translation='1 2 0'> |
| 43 | <Shape> |
| 44 | <Sphere radius='.5'/> |
| 45 | <Appearance> |
| 46 | <Material diffuseColor='0 1 0'/> |
| 47 | </Appearance> |
| 48 | </Shape> |
| 49 | </Transform> |
| 50 |
<!-- ROUTE information for FrontTouchSensor node:
[from touchTime to FRONTTOUCHSENSORCLOCK.set_startTime
]
-->
<TouchSensor DEF='FrontTouchSensor' description='front TouchSensor'/> |
| 51 |
<!-- ROUTE information for FRONTTOUCHSENSORCLOCK node:
[from FrontTouchSensor.touchTime to set_startTime
]
[from fraction_changed to PlaqueToPictureInterpolator.set_fraction
]
-->
<TimeSensor DEF='FRONTTOUCHSENSORCLOCK' cycleInterval='2'/> |
| 52 |
<!-- ROUTE information for PlaqueToPictureInterpolator node:
[from FRONTTOUCHSENSORCLOCK.fraction_changed to set_fraction
]
[from value_changed to BLUEROCKFISH_TRANSFORM.set_rotation
]
-->
<OrientationInterpolator DEF='PlaqueToPictureInterpolator' key='0.0 0.50 1.0' keyValue='0.0 1.0 0.0 3.14 0.0 1.0 0.0 1.57 0.0 1.0 0.0 0.00'/> |
| 53 | </Group> |
| 54 | <Group> |
| 55 | <Transform DEF='BUTTON_TRANSFORM2' translation='-1 2 0'> |
| 56 | <Shape> |
| 57 | <Sphere radius='.5'/> |
| 58 | <Appearance> |
| 59 | <Material diffuseColor='1 0 0'/> |
| 60 | </Appearance> |
| 61 | </Shape> |
| 62 | </Transform> |
| 63 |
<!-- ROUTE information for PictureTouchSensor node:
[from touchTime to BLUEROCKFISHCLOCK.set_startTime
]
-->
<TouchSensor DEF='PictureTouchSensor' description='picture TouchSensor'/> |
| 64 | </Group> |
| 65 | <Group> |
| 66 | <Transform DEF='BASE_TRANSFORM' translation='0 0 -.3'> |
| 67 | <Shape> |
| 68 | <Box size='8 6 .3'/> |
| 69 | <Appearance> |
| 70 | <Material diffuseColor='.3 .3 .6'/> |
| 71 | </Appearance> |
| 72 | </Shape> |
| 73 | </Transform> |
| 74 | <TouchSensor DEF='BaseTouchSensor' description='touch to rotate'/> |
| 75 | <Group> |
| 76 | <Transform translation='0 -2.6 0'> |
| 77 | <Shape> |
| 78 | <Box size='8 1 1'/> |
| 79 | <Appearance> |
| 80 | <Material diffuseColor='0.8 0.8 0.2'/> |
| 81 | </Appearance> |
| 82 | </Shape> |
| 83 | </Transform> |
| 84 | </Group> |
| 85 | <Group> |
| 86 | <Transform translation='0 2.6 0'> |
| 87 | <Shape> |
| 88 | <Box size='8 1 1'/> |
| 89 | <Appearance> |
| 90 | <Material diffuseColor='0.8 0.8 0.2'/> |
| 91 | </Appearance> |
| 92 | </Shape> |
| 93 | </Transform> |
| 94 | </Group> |
| 95 | <Group> |
| 96 | <Transform rotation='0 0 1 1.58' translation='3.6 0 0'> |
| 97 | <Shape> |
| 98 | <Box size='6.2 1 1'/> |
| 99 | <Appearance> |
| 100 | <Material diffuseColor='0.8 0.8 0.2'/> |
| 101 | </Appearance> |
| 102 | </Shape> |
| 103 | </Transform> |
| 104 | </Group> |
| 105 | <Group> |
| 106 | <Transform rotation='0 0 1 1.58' translation='-3.6 0 0'> |
| 107 | <Shape> |
| 108 | <Box size='6.2 1 1'/> |
| 109 | <Appearance> |
| 110 | <Material diffuseColor='0.8 0.8 0.2'/> |
| 111 | </Appearance> |
| 112 | </Shape> |
| 113 | </Transform> |
| 114 | </Group> |
| 115 | </Group> |
| 116 | </Group> |
| 117 | < ROUTE fromNode='BlueRockfishTouchSensor' fromField='touchTime' toNode='BLUEROCKFISHCLOCK' toField='set_startTime'/> |
| 118 | < ROUTE fromNode='BLUEROCKFISHCLOCK' fromField='fraction_changed' toNode='BlueRockfishPathInterpolator' toField='set_fraction'/> |
| 119 | < ROUTE fromNode='BlueRockfishPathInterpolator' fromField='value_changed' toNode='BLUEROCKFISH_TRANSFORM' toField='set_rotation'/> |
| 120 | < ROUTE fromNode='FrontTouchSensor' fromField='touchTime' toNode='FRONTTOUCHSENSORCLOCK' toField='set_startTime'/> |
| 121 | < ROUTE fromNode='FRONTTOUCHSENSORCLOCK' fromField='fraction_changed' toNode='PlaqueToPictureInterpolator' toField='set_fraction'/> |
| 122 | < ROUTE fromNode='PlaqueToPictureInterpolator' fromField='value_changed' toNode='BLUEROCKFISH_TRANSFORM' toField='set_rotation'/> |
| 123 | <!-- Picture touch sensor only has to tie into the BLUEROCKFISHCLOCK so that it will turn picture. --> |
| 124 | < ROUTE fromNode='PictureTouchSensor' fromField='touchTime' toNode='BLUEROCKFISHCLOCK' toField='set_startTime'/> |
| 125 | </Scene> |
| 126 | </X3D> |
DEF nodes index:
BASE_TRANSFORM,
BaseTouchSensor,
BLUEROCKFISH_TRANSFORM,
BLUEROCKFISHCLOCK,
BlueRockfishPathInterpolator,
BlueRockfishTouchSensor,
BUTTON_TRANSFORM,
BUTTON_TRANSFORM2,
FrontTouchSensor,
FRONTTOUCHSENSORCLOCK,
PictureTouchSensor,
PlaqueToPictureInterpolator,
stripedsurfperch
Event Graph ROUTE Table entries with 7 ROUTE connections total, showing X3D event-model relationships for this scene.
Each row shows an event cascade that may occur during a single timestamp interval between frame renderings, as part of the X3D execution model.
|
BaseTouchSensor
TouchSensor |
description='touch to rotate' User-interaction hint for this node.(TouchSensor description is providing a tooltip) |
|
BlueRockfishTouchSensor
TouchSensor touchTime SFTime |
BLUEROCKFISHCLOCK
TimeSensor set_startTime SFTime |
then
|
BLUEROCKFISHCLOCK
TimeSensor fraction_changed SFFloat |
BlueRockfishPathInterpolator
OrientationInterpolator set_fraction SFFloat |
then
|
BlueRockfishPathInterpolator
OrientationInterpolator value_changed SFRotation |
BLUEROCKFISH_TRANSFORM
Transform set_rotation SFRotation |
|
FrontTouchSensor
TouchSensor touchTime SFTime |
FRONTTOUCHSENSORCLOCK
TimeSensor set_startTime SFTime |
then
|
FRONTTOUCHSENSORCLOCK
TimeSensor fraction_changed SFFloat |
PlaqueToPictureInterpolator
OrientationInterpolator set_fraction SFFloat |
then
|
PlaqueToPictureInterpolator
OrientationInterpolator value_changed SFRotation |
BLUEROCKFISH_TRANSFORM
Transform set_rotation SFRotation |
|
PictureTouchSensor
TouchSensor touchTime SFTime |
BLUEROCKFISHCLOCK
TimeSensor set_startTime SFTime |
then
|
BLUEROCKFISHCLOCK
TimeSensor fraction_changed SFFloat |
BlueRockfishPathInterpolator
OrientationInterpolator set_fraction SFFloat |
then
|
BlueRockfishPathInterpolator
OrientationInterpolator value_changed SFRotation |
BLUEROCKFISH_TRANSFORM
Transform set_rotation SFRotation |
<!--
Color-coding legend: X3D terminology
<X3dNode
DEF='idName' field='value'/>
matches XML terminology
<XmlElement
DEF='idName' attribute='value'/>
(Light-blue background: event-based behavior node or statement)
(Grey background inside box: inserted documentation)
(Magenta background: X3D Extensibility)
-->
<!--
